MB-INMRB CleatMax™ cleated range

Rock and no rollback.

MRB CleatMax

Aggregate Cleated Belts · by Malone Road Belt

Cleated belt running up a steep incline conveyor inside a recycling plant
1 / 5

A MRB CleatMax™ cleated belt range built for aggregate duty: crushed rock, screened material and everything a quarry throws at it. The cleat profiles are integrally hot-molded into the belt's top cover — not glued or bolted on — so they grip the belt as firmly as the belt grips the load, extending belt life and keeping material moving up steep inclines.

Pair the cleat pattern with a heavy-duty base belt such as Bulldog Cleat for cut, impact and wear resistance with excellent troughability. Our team will match cleat profile, height and pitch to your incline angle, material and belt speed.

  • Cleats hot-molded into the top cover for superior adhesion
  • Profiles matched to incline angle, material type and belt speed
  • Popular 15 mm, 25 mm and 32 mm cleat heights, optional V-joints
  • Heavy-Duty base belt options
  • Available as full rolls, cut lengths, endless or MRB ZIP® prepared
In this range

10 belts, ready to spec.

Filter by pattern
MB-IN-C15P385
3D render of the C15P385 chevron pattern molded on a conveyor belt
MB-IN-C15P385

C15P385 Chevron Pattern

Profile
C15P385
Cleat height
15 mm
Cleat width
400 mm
Made to orderView product
MB-IN-C15V450
3D render of the C15 chevron profile (C15P385 pattern shown, representative of the range)
MB-IN-C15V450

C15V450 Chevron Pattern

Profile
C15V450
Cleat height
15 mm
Cleat width
450 mm
Made to orderView product
MB-IN-C32P460
3D render of the C32 heavy chevron profile (C32P580 pattern shown, representative of the range)
MB-IN-C32P460

C32P460 Chevron Pattern

Profile
C32P460
Cleat height
32 mm
Cleat width
460 mm
Made to orderView product
MB-IN-S25P750
Technical plan drawing of the S25P750 cleat pattern with dimension callouts
MB-IN-S25P750

S25P750 Cleat Pattern

Profile
S25P750
Cleat height
25 mm
Cleat width
750 mm
Made to orderView product
MB-IN-C25P1000
3D render of the C25P1000 chevron pattern molded on a conveyor belt
MB-IN-C25P1000

C25P1000 Chevron Pattern

Profile
C25P1000
Cleat height
25 mm
Cleat width
1000 mm
Made to orderView product
MB-IN-C15P540
3D render of the C15 chevron profile (C15P385 pattern shown, representative of the range)
MB-IN-C15P540

C15P540 Chevron Pattern

Profile
C15P540
Cleat height
15 mm
Cleat width
540 mm
Made to orderView product
MB-IN-Y26V400
3D render of the Y-profile cleat pattern (Y32P600 shown, representative of the range)
MB-IN-Y26V400

Y26V400 Cleat Pattern

Profile
Y26V400
Cleat height
26 mm
Cleat width
425 mm
Made to orderView product
MB-IN-C15P800
3D render of the wide C15 chevron profile (C15P750 pattern shown, representative of the range)
MB-IN-C15P800

C15P800 Chevron Pattern

Profile
C15P800
Cleat height
15 mm
Cleat width
800 mm
Made to orderView product
MB-IN-Y26V330
3D render of the Y-profile cleat pattern (Y32P600 shown, representative of the range)
MB-IN-Y26V330

Y26V330 Cleat Pattern

Profile
Y26V330
Cleat height
26 mm
Cleat width
330 mm
Made to orderView product
MB-IN-C15P500
3D render of the C15 chevron profile (C15P385 pattern shown, representative of the range)
MB-IN-C15P500

C15P500 Chevron Pattern

Profile
C15P500
Cleat height
15 mm
Cleat width
500 mm
Made to orderView product
